5 Ton/60k BTU MRCOOL® VersaPro® 2nd Generation Central Ducted Heat Pump Condenser & Air Handler Bundle
5 Ton/60k BTU MRCOOL® VersaPro® 2nd Generation Central Ducted Heat Pump Condenser & Air Handler Bundle is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Care information
Care information
Care kits are available on our website! Grab yours now.
Delivery and Shipping
Delivery and Shipping
Delivery times may vary by location but our delivery shipping times are 3-7 days.
Specifications
Specifications
Specifications
Specifications
5 Ton MRCOOL® VersaPro® 2nd Generation Central Ducted Heat Pump Condenser | |
SEER2 | 15.2 |
EER2 | 8.6 |
HSPF-4 | 8.4 |
HSPF-5 | 6.8 |
CFM | 3037.1 |
TONNAGE | 5 |
COOLING CAPACITY (BTU) | 54000 |
HEATING CAPACITY (BTU) | 54000 |
VOLTAGE (V) | 208-230 |
PHASE | 1 |
CYCLE | 60 |
MAX FUSE BREAKER (A) | 40 |
MIN CIRCUIT AMPACITY (A) | 39 |
COLOR | gray |
REFRIGERANT TYPE | R454B |
REFRIGERANT VOLUME (OZ) | 134.04 |
DECIBEL RATING (DBA) | 65 |
LIQUID LINE SIZE | 3/8 |
SUCTION LINE SIZE | 3/4 |
WIFI COMPATIBILITY | Yes |
APP COMPATIBILITY | Yes |
ETL CERTIFIED | Yes |
ENERGY STAR CERTIFIED | Yes |
AHRI CERTIFIED | Yes |
BASE PARTS WARRANTY | 10 Years |
BASE COMPRESSOR WARRANTY | 10 Years |
CONTAINS ELECTRONICS | Yes |
CONTAINS CHEMICALS | Yes |
CONTAINS COMPRESSED GAS | Yes |
NET DEPTH (IN) | 16.34 |
NET HEIGHT (IN) | 38.39 |
NET WIDTH (IN) | 38.58 |
NET WEIGHT (LBS) | 192.9 |
GROSS DEPTH (IN) | 19.68 |
GROSS HEIGHT (IN) | 42.52 |
GROSS WIDTH (IN) | 45.08 |
GROSS WEIGHT (LBS) | 224.21 |
5 Ton MRCOOL® VersaPro® 2nd Generation Central Ducted Air Handler | |
CFM | 1807.00/1583.33/1359.67/1136.00 |
TONNAGE | 5 |
COOLING CAPACITY (BTU) | 54000 |
HEATING CAPACITY (BTU) | 54000 |
VOLTAGE (V) | 115/208-230 |
PHASE | 1 |
CYCLE | 60 |
MAX FUSE BREAKER (A) | 15 |
MIN CIRCUIT AMPACITY (A) | 14.5/11.0 |
COLOR | gray |
DECIBEL RATING LOW (DBA) | 34.5 |
DECIBEL RATING HIGH (DBA) | 56 |
NUMBER OF SPEEDS | 4 |
MAX LINESET LENGTH (FT) | 246 ft |
LIQUID LINE SIZE | 3/8 |
SUCTION LINE SIZE | 3/4 |
FILTER TYPE | Replaceable |
FILTER SIZE | 23x20x1 |
AUXILIARY HEATER INCLUDED | No |
AUXILIARY HEATER AVAILABLE | Yes |
AUXILIARY HEATER SIZES | 10kW/15kW/20kW |
ADJUSTABLE THERMOSTAT | Yes |
WIFI COMPATIBILITY | Yes |
APP COMPATIBILITY | Yes |
ETL CERTIFIED | Yes |
ENERGY STAR CERTIFIED | Yes |
AHRI CERTIFIED | Yes |
BASE PARTS WARRANTY | 10 Years |
BASE COMPRESSOR WARRANTY | 10 Years |
CONTAINS ELECTRONICS | Yes |
CONTAINS CHEMICALS | Yes |
CONTAINS COMPRESSED GAS | Yes |
NET DEPTH (IN) | 24.49 |
NET HEIGHT (IN) | 52.99 |
NET WIDTH (IN) | 21.02 |
NET WEIGHT (LBS) | 162.92 |
GROSS DEPTH (IN) | 26.77 |
GROSS HEIGHT (IN) | 56.5 |
GROSS WIDTH (IN) | 27.95 |
GROSS WEIGHT (LBS) | 190.92 |
Description
Description
***BUNDLE DOES NOT COME WITH LINE SET OR HEAT KIT, UNLESS ADDED***
Bundle contains:
Quantity 1x: 5 Ton/60k BTU MRCOOL® VersaPro® 2nd Generation Central Ducted Heat Pump Condenser
Quantity 1x: 5 Ton/60k BTU MRCOOL® VersaPro® 2nd Generation Central Ducted Air Handler
Description:
The 5 Ton MRCOOL® VersaPro® 2nd Generation Central Ducted Heat Pump Condenser and Air Handler deliver a powerful and efficient year-round climate control solution for homes up to 2,500 square feet. Featuring a SEER2 rating of 16 and an HSPF4 rating of 8.4, this system ensures energy-efficient performance while providing reliable heating and cooling in any season. The 60K BTU variable-speed capacity is enhanced by DC inverter technology, which optimizes operation for reduced energy consumption and quieter performance. Designed for durability, the system features a painted galvanized steel construction and a compact side-discharge design, allowing for flexible installation even in smaller spaces. Adaptable to different home layouts, it supports upflow, downflow, and horizontal left or right configurations for seamless integration. Maintenance is simplified with an integrated self-diagnostics panel, quickly identifying issues to reduce service interruptions. The system also prioritizes sustainability, utilizing eco-friendly R-454B refrigerant to minimize environmental impact. For convenience, the MRCOOL® Smart Thermostat provides precise temperature control, and compatibility with the MRCOOL® SmartHVAC app enables remote adjustments from anywhere. An optional heat kit is available for enhanced warmth in colder months. Backed by a 10-year warranty covering the compressor and parts, the 5 Ton MRCOOL® VersaPro® system is a reliable, energy-efficient upgrade designed to provide long-lasting comfort and performance for your home.
